Compact high brightness laser projector
The ZW400 is a compact WXGA DuraCore IP6X laser projector. Designed for maintenance-free continuous operation, it can be installed in virtually any orientation. Its small and lightweight footprint, 1.3x zoom combined with 360-degree and portrait projection make it a breeze to install.
This feature-packed projector is 4K and HDR compatible, has a built-in speaker and its laser technology delivers up to 30,000 hours maintenance-free laser light source. For ultimate control, the projector comes with RJ45 connection allowing you to monitor and control your network in multiple rooms.
Geared for medium-sized exhibition venues, events, tradeshows or meeting rooms, it maintains excellent image quality as brightness and colour saturation is preserved for longer compared to lamp systems.
DuraCore
Industry leading lifetime is achieved using Optoma’s DuraCore technology. Implementing advanced laser diode cooling techniques and an innovative dust resistant design.
IP6X Airtight optical engine
Independently tested and certified to IEC standard 60529 with an IP6X dust resistance rating. Outstanding dust resistance combined with exceptional brightness ensures industry leading durability; paramount for 24/7 maintenance free operation in challenging environments.
HDR compatible
Capable of receiving and displaying HDR meta data, Optoma HDR compatible projectors allow you to see far more detail and texture. Objects look more solid and life like and the extra detail creates a greater sense of depth. It’s like looking through a window.
Superior contrast
Add more depth to your image with a high contrast projector. Compared to competing technology, Optoma DLP projectors provide you with brighter whites and ultra-rich blacks, images come alive and text appears crisp and clear – ideal for business and education applications.
Amazing colour
Optoma projectors provide reliable colour performance suitable for any content and environment. From accurate sRGB colours for lifelike images to vibrant punchy presentations. We have a display mode to specific meet your needs. Perfect for a range of graphic and video presentations.
Portrait projection
Ideal for digital signage applications you can rotate your projector 90 degrees to project a portrait image.
360 projection*
Images can be projected over a 360° range* along the projector’s horizontal axis.
*For more information please refer to the user manual
Control
Featuring a wide range of options you can control and monitor the projector remotely.
• RS232 Optoma projector’s come with an extensive set of RS232 commands making it simple and easy to manage using any control system.
• AMX compatible Dynamic discovery protocol is incorporated into the projector allowing for easy installation with AMX control systems.
• Crestron RoomView Using the compatible RoomView® software you can power on/off, monitor, manage and control up to 250 projectors at the same time from any computer
• Extron IPLink compatible Allows for easy installation with Extron control systems
PJLink
PJLink protocol is incorporated into the projector allowing for easy installation with PJLink compatible control systems.
Telnet
This model is able to receive comands via telenet allowing for easy installation with Telnet compatible control systems.
Full 3D
Optoma projectors can display true 3D content from almost any 3D source, including 3D compatible graphics cards, 3D broadcasting and the latest generation 3d media servers.
Integrated speaker
A powerful built-in speaker provides exceptional sound quality and an easy setup without the need for costly external speakers.
USB-Power
Use the USB-A port to power an HDMI dongle, such as Google Chromecast.
AV mute
Stay in control of your presentation with AV mute. Direct your audience’s attention away from the screen by blanking the image when not needed.
Auto power off
There may be instances when the projector is left running when not in use. To help save energy, the “auto power off” feature automatically turns off the projector after a set period of time if it is not being used
Quick resume
This feature allows the projector to be instantly powered on again, if it is accidentally switched off.
Direct power on
The projector will start up instantly when power is supplied to the unit. This eliminates the need to manually turn on the projector via the remote control or the keypad, ideal for use in rooms with a “master” power switch.
Direct power off
Power off your projector immediately or directly at the mains. This means you don’t have to wait for the projector to cool down before turning it off.
24/7 operation
Optoma projectors have been designed to operate 24 hours a day in standard orientation. Perfect for applications where prolonged periods of use is required. Subject to 24 hour terms and conditions.
24/7 Operation – standard lamp warranty applies. Projector warranty is based on standard business usage hours. For optimum performance Optoma recommends that your projector is turned off or placed in standby mode for 30 minutes every 24 hours to prolonging the life of your lamp.
Display/image-
Display technology – DLP™
Resolution – WXGA (1280×800)
Brightness – 4,000 lumens
Contrast ratio – 250,000:1
Native aspect ratio – 16:10
Aspect ratio – compatible – 4:3,16:9
Keystone correction – vertical – +/-40°
Has vertical auto keystone correction – Yes
Displayable colours (millions) – 1073.4
Horizontal scan rate – 15.375 ~ 91.146 Khz
Vertical scan rate – 50 ~ 85 Hz (120Hz for 3D)Hz
Uniformity – 85%
Screen size – 0.76m ~ 7.65m (30″ ~ 301″) diagonal
Lamp info-
Light source type – Laser
LASER life – 30,000 hours
Optical-
Throw ratio – 1.18:1 ~ 1.54:1
Projection distance (m) – 1m – 7.7m
Zoom – 1.3
Zoom type – Manual
Focal length (mm) – 16.901mm~21.6076mm/0.665″~0.851″
Native offset – 113%
Connectivity-
Connections – Inputs 1 x HDMI 2.0, 1 x HDMI 1.4a 3D support, 1 x VGA (YPbPr/RGB), 1 x Audio 3.5mm
Outputs 1 x Audio 3.5mm, 1 x USB-A power 1.5A
Control 1 x RS232, 1 x RJ45, 1 x micro USB service
General-
Noise level (typical) – 30dB
Noise level (max) – 32dB
PC compatibility – UHD, FHD, UXGA, SXGA, WXGA, HD, XGA, SVGA, VGA, Mac
2D compatibility – NTSC M/J, 3.58MHz, 4.43MHz PAL B/D/G/H/I/M/N, 4,43MHz SECAM B/D/G/K/K1/L, 4.25/4.4MHz 480i/p, 576i/p, 720p(50/60Hz), 1080i(50/60Hz), 1080p(50/60Hz)
3D compatibility – Side-by-Side:1080i50 / 60, 720p50 / 60 Frame-pack: 1080p24, 720p50 / 60 Over-Under: 1080p24, 720p50 / 60
3D – Full 3D
Security – Security bar, Kensington Lock, Password protected interface
IP rating – IP6X
OSD / display languages – 25 languages: Arabic, Czech, Danish, Dutch, English, Farsi, Finnish, French, German, Greek, Hungarian, Indonesian, Italian, Japanese, Norwegian, Polish, Portuguese, Romanian, Russian, Chinese (simplified), Spanish, Swedish, Chinese (traditional), Turkish, Vietnamese
24/7 operation – Yes
Operating conditions – 5°C~40°C/41°F~104°F, max altitude 3000M/9843ft, max humidity 85%
Remote control – Data remote with laser and mouse function
Speaker count – 1
Watts per speaker – 10W
In the box -AC power cord
Remote control
2x AAA batteries
Basic user manual
Optional wireless models – UHDCast Pro
Networking-
LAN – control – Yes
Power-
Power supply – 100V ~ 240V, 50-60Hz
Power consumption (standby) – <0.5W
Power consumption (min) – 157W
Power consumption (max) – 211W
Weight and dimensions-
Dimensions (W x D x H) mm – 337 x 265 x 122.5
Gross weight – 6.6 kg
Net weight – 4.264 kg
