Creative Touch 3 Series 86″ interactive flat panel display
Robust collaboration, extensive connectivity options and a value-focused design. Combining the latest technology and packed with everything a classroom or business requires, the Creative Touch 3 Series delivers all the functionalities and processing power needed to create, educate and collaborate.
Easily access the front-facing ports for HDMI and USB connectivity. For wireless connectivity, Optoma’s TapCast Pro allows up to four users to share content at the same time from their Windows, iOS, macOS, Chrome or Android device.
The easy-to-use IFPDs also make lessons more fun with built-in collaboration tools such as Vote, where teachers are able to collect valuable feedback instantly.
Equipped with an OPS slot, and easy to download OTA updates, the touchscreen display is future-proofed should your requirements change in the ever-changing world of technology. (OPS sold separately).
Advanced interaction and collaboration
TapCast Pro interactive wireless collaboration toolset
Advanced touch technology
Pen and finger recognition for a seamless experience
Dual App mode
Run two applications at the same time on the screen
Safe and secure viewing experience
Anti glare and anti finger print, low blue light and flicker free TUV certified
Ultra HD 4K resolution
With over eight million pixels, Ultra HD 4K resolution brings four times more detail than Full HD, to deliver sharper, life-like images and richer colours – allowing you to sit closer to the screen and enjoy a more immersive experience.
TUV Certified Low blue light display
The built-in low blue light mode helps reduce eyestrain and tiredness by minimising the blue light output from the display.
Disclaimer for unauthorised apps on OP series Android-based interactive displays:
For system security, Optoma interactive flat panel displays run on a customised Android operating system. Additionally Optoma interactive flat panel displays do not support Google Play Services. Optoma has streamlined the Android operating system so only modules related to display features remain. The customised Android operating system may not be compatible with all third-party Android apps. Third-party Android apps can vary in quality and some even contain malicious codes, which could compromise system security and functionality and may invalidate your product warranty.
Optoma makes no representations regarding the quality, security or suitability of any third-party apps and their compatibility with the Optoma interactive flat panel. Optoma shall have no responsibility or liability with respect to any damage, faults, loss in functionality or security issues arising as a direct or indirect result of the installation of third-party apps on the interactive flat panel. Optoma support in rectifying any issue which may result from the installation of third-party apps will be chargeable and may be limited.
Optoma TeamShare: whiteboard and annotation
Creative sharing is easy with a ready-to-use whiteboard featuring built-in annotation tools that encourage collaboration.
Optoma file manager
Optoma file manager allows users to manage files and folders. Users can also access cloud drives and browse, create, rename, copy, move and delete files.
TapCast collaboration tool
What is TapCast? Wirelessly display and share content on a big screen without any additional hardware using the TapCast app. Easily mirror your Android, iOS, Windows, macOS or Chrome device at the touch of a button. You can even wirelessly cast documents, images or videos stored on your mobile device or laptop.
The app also acts as a wireless mouse and keyboard allowing you to control your device.
Cloud Whiteboard
Connect easily.
Sync with your cloud accounts to plan your lessons from anywhere, at any time. As Creative Board is a cloud-based platform, you can access your lesson materials from any Optoma Creative Touch 5-Series IFPD in your school
Dual app mode
This allows you to view two apps on your device at the same time. Use dual app mode to view content while you scan related Office documents – turning your IFPD into the ultimate multi-tasking device.
Ambient light sensor
The built-in light sensor detects the amount of ambient lighting surrounding the panel and adjusts the display accordingly in order to guarantee an optimal picture quality and the best viewing experience possible.
Screen recording
Optoma Creative Touch 3 Series comes with video recording functionality that allows teachers to record their lectures or businesses to record their meetings for preparation or review purposes.
Specification
Display-
Back light – Direct type LED
Size (diagonal) – 86″
Resolution – 3840×2160
Brightness – 370
Contrast ratio – 1,200:1
Contrast ratio (dynamic) – 4,000:1
Viewing angle – 178°
Response time – 8ms
Life – 50,000 hours
Display colours – 1,070
Speaker count – 2
Watts per speaker – 15W
Surface hardness – 7H
Glass -Anti Glare + Anti Finger Print / HAZE 2-6%
Ambient light sensor – Yes
Air gap – 4.00mm
Physical Spec-
Dimensions (W x D x H) mm – 2019 x 1209 x 116
Wall-hanging screw spec – M8*25mm
VESA holes – 800*400
In the box – European Standard Power Cord
American Standard Power Cord
British Standard Power Cord
USB Cable
HDMI Cable
Writing Pen x2
Remote Control
Battery
Pen holder/ Pen tray
QSG
Connections – Inputs 3 x HDMI 2.0, 1 x VGA, 1 x DisplayPort, 1 x Audio 3.5mm, 4 x USB 2.0, 1 x USB 3.0, 1 x RJ45
Outputs 1 x HDMI 2.0, 1 x S/PDIF, 1 x Audio 3.5mm, 1 x RJ45
Control 5 x USB-A (Interactive), 1 x RS232
Bezel size (top) – 27.00mm
Bezel size (left) – 27.00mm
Bezel size (right) – 27.00mm
Operating conditions – 20% ~ 80% RH
Operating temperature (max) – 40°C
Net weight – 73 kg
Gross weight -90 kg
Wireless – operating frequency – 2.4G/5G
Touch system-
System – Windows10/Windows8/Windows7/Windows XP /Linux/Mac (1 Touch point only)/Android/Chrome
Touch accuracy – <1.50mm
Touch point – 20
Touch tool – Finger, Passive infrared pen
Pen/finger detection – Yes
Power-
Power supply – 100-240V~ 50/60Hz 3.5A
Power consumption (standby) – 0.5W
Power consumption (max) – 450W
Power consumption – average (watts) – 179.3
Operation system-
System version – Android 8.0
CPU -Dual-core A73 and dual-core A53
GPU – Mali G51*2
RAM – 3GB
Storage – 16GB
OSD / display languages – 18 languages: Arabic, Czech, Danish, Dutch, English, French, German, Italian, Polish, Portuguese, Romanian, Russian, Chinese (simplified), Spanish, Swedish, Chinese (traditional), Turkish
