It is optimized in the ISM 2.4 GHz band to amplify the antenna signal,
offering 20 dB gain to compensate for signal loss over long antenna
cables and to increase the reception range and signal stability.
The antenna booster can be powered by the bias of the receiver’s
antenna connector or by an external power supply, allowing longer
antenna cables can be connected with more boosters.
With an aluminum casing, it features superb heat dissipation and
waterproof.
Specifications
Frequency Range 2.4 GHz
Gain Fixed, approx. 20 dB
Input / Output
Connectors
1-to-1 TNC. 50 Ω Impedance.
Input Power 10 ~ 24 V DC
Regulated Power Output Equals to the bias
Dimensions 41 × 80 × 24 mm (W×H×D)
Weight Approx. 260 g
Note Refer to the actual product in the event of product description discrepancy
