- Compact and lightweight rugged plastic housing for easy to wear.
- On top of the housing is equipped with an antenna, mute button and mini XLR connector. The Mini XLR audio input connector accepts either a screw-lock or a TA4F quick-lock plug. A remote-control mute jack is for easy activation of the mute function.
- An LCD on the panel displays the working channel, battery status and operating information.
- Powered by two AA alkaline batteries.
- Innovatively designed battery cover allows easy access to operate buttons and prevent accidental operation.
- High/low impedance for microphone or guitar / line inputs. Five selectable gain settings with Auto Limiter to prevent distortion.
| Model | ACT-32T |
|---|---|
| Name | UHF Bodypack Transmitter |
| Mic Capsule Modules | Paired lavalier mic MU-55L or optional other MIPRO’s lavalier and headworn mic capsule modules. |
| Max. Audio Input | 0 dBV |
| Display | Green backlit LCD |
| Frequency Range | UHF 480 ~ 934 MHz (country dependent) |
| Bandwidth | 24 MHz |
| Input Impedance Setting | High impedance |
| RF Power Output | 10 mW / 50 mW switchable (country dependent) |
| Spurious Emission | < 4 nW |
| Battery | Two AA alkaline |
| Dimensions | 63 × 82 × 22 mm (W×H×D) |
| Weight | Approx. 86 g |
