Allen & Heath Qu-7D

Ettetellimisel

Compact 38in/24out 96kHz Digital Mixer with Dante

Ilma käibemaksuta 2868.03€

Algne hind oli: 3599.00€.Current price is: 3499.00€.

Kogus
Tootekood: QU-7D Kategooria: Silt:
Ask for delivery time
×

    Küsi abi

    Ross

    [email protected]

    +372 5699 7759

    Tasuta tarne, kui e-poe tellimuse summa ületab 139€
    14-päevane raha tagasi garantii
    Kui kaup on laos, saad toote kätte järgmisel tööpäeval!

    Allen & Heath Qu-7D – 38-In/24-Out 96kHz Digital Mixer with Dante

    Flagship Performance with Integrated Dante Networking

    The Allen & Heath Qu-7D is a top-tier 96kHz digital mixer designed for professional live sound, broadcast, and studio applications. Combining advanced XCVI FPGA processing with a 16×16 Dante interface, the Qu-7D offers unparalleled audio quality, flexible I/O, and seamless integration into modern digital audio networks.

    🎚️ Key Features

    • 96kHz XCVI Core Processing
      Delivers ultra-low latency and high-resolution audio for pristine sound quality.

    • 38 Inputs to Mix
      Includes 32 mono (linkable) and 3 stereo channels, providing flexibility for various input configurations.

    • 32 Premium Mic Preamps
      Digitally controlled for precise gain settings and recallable configurations.

    • 33 Motorized Faders
      Smooth 100mm faders across 4 layers offer intuitive control over your mix.

    • 7” Capacitive Touchscreen
      Provides clear visual feedback and easy navigation through settings and parameters.

    • Integrated Dante Interface
      16×16 channels at 48/96kHz for seamless audio-over-IP networking.

    • Versatile I/O Configuration

      • Inputs: 32 XLR/Jack combo mic/line, 2 stereo TRS line inputs.

      • Outputs: 20 XLR, 2 TRS, 1 AES3 digital, and a dedicated talkback XLR.

    • Comprehensive Mixing Architecture

      • 12 mix outputs (6 mono/linkable aux/group, 6 stereo aux/group).

      • 4 mono/linkable matrix outputs.

      • Stereo Main LR output.Gearnews.com

    • 6 Multi-FX Engines
      Each with dedicated stereo returns, offering a range of high-quality effects.

    • Recording & Playback Options

      • 32×32 USB-C audio interface for multitrack recording/playback.

      • SD card slot supports 16×16 recording at 96kHz or 32×32 at 48kHz.

      • USB-A port for stereo recording/playback and data transfer.

    • Remote Control
      Compatible with free apps for Windows, macOS, iOS, and Android, allowing wireless control over mixing parameters.

    • Expandable via SLink
      128×128 Intelligent SLink port enables connection to Everything I/O stageboxes and interfaces.

    📐 Technical Specifications

    • Dimensions: 800mm (W) x 476mm (D) x 211mm (H)

    • Weight: 16.7 kg

    • Power: IEC mains connection with worldwide PSU

    • Mounting: 19” rackmount format (optional rack kit available)

    The Allen & Heath Qu-7D stands out as a versatile digital mixer, offering high-end features in a compact design. Its integration of advanced processing, flexible I/O, and network capabilities makes it an ideal choice for professionals seeking reliability and performance in various audio environments.
