Specifications:
OPTICAL:
• Light Source: 1x 150-Watt COB (Chip on Board) Quad LED (RGBA: 4-IN-1, rated at approximately 50,000 hrs)
• Light Output: 1970 LUX @2M; 474 LUX @4M (40-degree beam), 1472 LUX @2M; 373 LUX @ 4M (50-degree beam), 996 LUX @2M; 238 LUX @4M (80-degree beam)
• 80-degree beam angle
• Includes lens kit to change to 40-degrees or 50-degrees beam angle
CONNECTIONS:
• 3-pin & 5-pin connectors for DMX linking
• Power Twist AC IN/OUT to daisy chain power (up to 5 fixtures)
CONTROL:
• 7 DMX Channel modes (3,4,6,7,8, 8A,10, 11 Ch.)
• 64 built-in color macros
• 4-button digital DMX display on rear panel
• Compatible with wireless remote control (sold separately)
• LED pulse and strobe effect
• Electronic Dimming: 0 – 100%
• 6 selectable Dim Curves (Standard, Stage, TV, Architectural, Theatre & Stage 2)
• Refresh Rate:1KHz
FEATURES:
• Flicker Free operation (No flickering on camera)
• Produces powerful, smooth RGBA color mixing with rich palettes of color
• Use as Wash/par or Pixel Mapped for a stunning visual effect
• Scissor yoke allows fixture to be mounted on truss or set on the ground
• Optional Barn Doors sold separately
• Run all night – No duty cycle
ELECTRICAL:
• Auto sensing power supply: AC 100V/60Hz – 240V/50Hz
• Power Draw: 132W max
• Daisy chain up to 5 fixtures maximum
DIMENSIONS / WEIGHT:
• Dimensions (LxWxH): 13” x 8.5” x 7.5” / 330×218,5x190mm (with bracket); 10” x 7.5” x 7.5” / 256x190x190mm (without bracket)
• Weight: 9.2 lbs. / 4.2 kg.
