Acoustical specifications
- FREQUENCY RESPONSE: 50 Hz ÷ 20000 Hz
- MAX SPL @ 1M: 137 dB
- HORIZONTAL COVERAGE ANGLE: 100°
- VERTICAL COVERAGE ANGLE: 15°
Transducers
- COMPRESSION DRIVER: 1 x 1.4” neo, 4.0” v.c
- WOOFER:2 x 10” neo, 2.5” v.c
Input/Output section
- INPUT SIGNAL: bal/unbal
- INPUT CONNECTORS:XLR, RDNet Ethercon
- OUTPUT CONNECTORS:XLR, RDNet Ethercon
- INPUT SENSITIVITY:+4 dBu
Processor section
- CROSSOVER FREQUENCIES:680 Hz
- PROTECTIONS:Thermal, RMS
- LIMITER:Soft Limiter
- CONTROLS:Preset, RDNet bypass
- RDNET:Yes
Power section
- TOTAL POWER:2200 W Peak, 1100 W RMS
- HIGH FREQUENCIES:600 W Peak, 300 W RMS
- LOW FREQUENCIES:1600 W Peak, 800 W RMS
- COOLING: Forced
- CONNECTIONS: Powercon IN/OUT
Standard compliance
- CE MARKING: Yes
Physical specifications
- CABINET/CASE MATERIAL: PP Composite
- HARDWARE: Array fittings
- HANDLES: 2 Side
- GRILLE:Steel
- COLOR:Black
Size
- HEIGHT: 293 mm / 11.54 inches
- WIDTH: 705 mm / 27.76 inches
- DEPTH:502 mm / 19.76 inches
- WEIGHT:25 kg / 55.12 lbs
Shipping informations
- PACKAGE HEIGHT:365 mm / 14.37 inches
- PACKAGE WIDTH:800 mm / 31.5 inches
- PACKAGE DEPTH:550 mm / 21.65 inches
- PACKAGE WEIGHT:28.2 kg / 62.17 lbs
