RCF HVL 15-LW– a three-way passive long-range acoustic system for casting sound over long distances. Equipped with two 15″ woofers, two 10″ midrange drivers and two 4″ titanium dome compression tweeters with voice coils. Can work in bi-amp mode. The HVL 15-L uses the latest generation of precision RCF drivers with neodymium magnets. The system delivers a maximum SPL of 144dB (in bi-amp mode) delivering 1000W RMS in the bass section and 900W RMS in the mid-high range. Crossover and equalization between the midrange and tweeters is supported by a built-in passive filter. The opening angle is 90° x 30° (D x V). The connectors are made in the form of a terminal block, durable and resistant to weathering. Made from Baltic birch plywood body painted with waterproof polyurethane paint.
Three-way long-range stadium loudspeaker
Rated power: 1000 W (LF) + 900 W (MF-HF) AES
Maximum sound pressure: 144 dB
Frequency response (-10 dB): 43 – 18,000 Hz
Angle Opening: 90°x30°
Equipped with RCF neodymium drivers
Bi-amp operation with passive filter between midrange and treble
Symmetrical horn design
Baltic birch plywood cabinet plus steel grille
Weatherproof
Type of system : 3-way passive loudspeaker
Frequency response (-10 dB): 43 – 18,000 Hz
Frequency response (-3 dB): 59 – 13,000 Hz
Maximum sound pressure at 1 m: 144 dB
Horizontal angle: 90°
Vertical angle: 30°
Sensitivity: 110 dB
Rated power: 1900 W RMS
Peak power: 7600 W
Program power: 3800 W
Protection: Dynamic active (mosfet-transistor)
Crossover frequency: 1800 Hz
RF compression driver 2×1.4” neodymium with 4.0” voice coil; nominal impedance 16 ohms, nominal input power 280 W AES, program power 560 W, sensitivity 110 dB (1 W at 1 m)
MF driver 2×10” neodymium with 3.0” voice coil; nominal impedance 8 ohm; nominal input power 500W AES, program power 1000W; sensitivity 112 dB (1 W at 1 m)
woofer 2×15” neodymium with 3.5” voice coil; nominal impedance 8 ohm; nominal input power 500W AES, program power 1000W; Sensitivity 97dB (1W at 1m)
Inputs/Outputs: Terminal Block
Body Colour: White
Mounting Options: Threaded bushings for suspension: 8 pieces M20 on each of the side walls, on the top and bottom of the cabinet
Protective grille: Steel
Body material : Plywood (Baltic birch)
Width: 1382 mm
Depth: 815 mm
Height: 525 mm
Weight:
3-Way Passive Long-Range Stadium Loudspeaker
RCF HVL 15-LW
Italy
2 years
White
Width 1382 mm Depth 815 mm Height 525 mm
110 kg
