Specifications:
Acoustical specifications
- FREQUENCY RESPONSE: 40 Hz ÷ 20000 Hz
- MAX SPL @ 1M: 140 dB
- HORIZONTAL COVERAGE ANGLE: 90°
- VERTICAL COVERAGE ANGLE: 10°
Transducers
- COMPRESSION DRIVER: 2 x 1.4” neo, 3.0” v.c
- MIDRANGE: 4 x 6.0” neo, 2.0” v.c
- WOOFER: 2 x 12” neo, 3.0” v.c
Input/Output section
- INPUT SIGNAL: bal/unbal
- INPUT CONNECTORS: XLR, RDNet Ethercon
- OUTPUT CONNECTORS: XLR, RDNet Ethercon
- INPUT SENSITIVITY: +4 dBu
Processor section
- CROSSOVER FREQUENCIES: 200 Hz – 800 Hz
- PROTECTIONS: Thermal, RMS
- LIMITER: Soft Limiter
- CONTROLS: Cluster size, HF correction, RDNET
Power section
- TOTAL POWER: 4400 W Peak, 2200 W RMS
- HIGH FREQUENCIES: 1100 W Peak, 550 W RMS
- MID FREQUENCIES: 1100 W Peak, 550 W RMS
- LOW FREQUENCIES: 2200 W Peak, 1100 W RMS
- COOLING: Convection
- CONNECTIONS: Powercon IN/OUT
Standard compliance
- CE MARKING: Yes
Physical specifications
- CABINET/CASE MATERIAL: Baltic birch plywood
- HARDWARE: Integrated Mechanics
- HANDLES: 2 side, 2 rear
- GRILLE: Steel
- COLOR: Black
Size
- HEIGHT: 366 mm / 14.41 inches
- WIDTH: 1171 mm / 46.1 inches
- DEPTH: 502 mm / 19.76 inches
- WEIGHT: 56 kg / 123.46 lbs
Shipping informations
- PACKAGE HEIGHT: 400 mm / 15.75 inches
- PACKAGE WIDTH: 1200 mm / 47.24 inches
- PACKAGE DEPTH: 600 mm / 23.62 inches
- PACKAGE WEIGHT: 60 kg / 132.28 lbs
