- Hybrid architecture DSP
- 48 KHz sampling, 40 bit floating point engine
- 16 x 16 I/O matrix
- Dante enabled network audio transport
- 8 AES/EBU inputs – 8 AES/EBU outputs
- Ethernet connectivity and control
- Maximum latency 3 ms
- Easy to use software GUI
DX 1616 AES-Dante remote software. This network-based software designed for Microsoft Windows and Mac OSX allows the management of the DX 1616 Matrix Sound Processor. -Pre-Amp configuration, selecting source types like analog, AES/EBU, Dante -Designing Input groups for festival applications -Input source processing with EQ, delay and compressor -Powerful 16×16 router to assign processing tasks to flexible output patches.
SPECIFICATIONS
AUDIO PERFORMANCE –
Frequency Response (-3dB): 20 Hz ÷ 22 kHz
Distortion (THD+N) @ 1 kHz nominal power: <0.001 %
Common Mode Rejection Ratio (50 Hz to 10 kHz): >100 dB
DIGITAL AUDIO PERFORMANCE –
Resolution: 40
INPUT SECTION –
Total number of inputs:17
Mic+Line connectors: Euroblock
Mic+Line Phantom: 21 V DC – 44 V DC
OUTPUT SECTION –
Signal output connectors: Euroblock
PROCESSING-
High-pass filter: 20 Hz ÷ 20000 Hz
Crossover: 20 ÷ 20000 Hz
CONTROLS
Configuration: PC Software
Number of programs/presets: 70
PROTECTIONS-
Cooling: Convection/Forced
Fuses: Yes
POWER REQUIREMENT-
Operating voltage:90-240 V~ 50/60Hz
Power consumption (MAX):20 W
STANDARD COMPLIANCE-
Safety agency: CE compliant
PHYSICAL SPECIFICATIONS
Cabinet/Case Material: Metal
Rack mounting: 19″, 1U
SIZE-
Height:44 mm / 1.73 inches
Width:483 mm / 19.02 inches
Depth:229 mm / 9.02 inches
Weight:3.31 kg / 7.3 lbs
SHIPPING INFORMATIONS
Package Height:378 mm / 14.88 inches
Package Width:88 mm / 3.46 inches
Package Depth:597 mm / 23.5 inches
Package Weight:4.73 kg / 10.43 lbs
