Specifications:
Acoustical specifications
- FREQUENCY RESPONSE (-10DB): 55 Hz ÷ 20000 Hz
- MAX SPL @ 1M: 133 dB
- HORIZONTAL COVERAGE ANGLE: 90°
- VERTICAL COVERAGE ANGLE: 60°
- SYSTEM SENSITIVITY: 99 dB
Power section
- CROSSOVER FREQUENCIES: 1400
Transducers
- COMPRESSION DRIVER: 1.4” neo, 3.0” v.c
- NOMINAL IMPEDANCE (OHM): 8 ohm
- INPUT POWER RATING: 110 W AES, 220 W PEAK
- SENSITIVITY (DB, 1W @ 1M): 109 dB, 1W @ 1m
- WOOFER: 15” neo, 3.5” v.c
- NOMINAL IMPEDANCE (OHM): 8 ohm
- INPUT POWER RATING: 650 W AES, 1300 W PEAK
- SENSITIVITY (DB, 1W @ 1M): 98 dB, 1W @ 1m
Input/Output section
- INPUT CONNECTORS: Speakon
- OUTPUT CONNECTORS: Speakon
Standard compliance
- CE MARKING: Yes
Physical specifications
- CABINET/CASE MATERIAL: PP Composite
- HARDWARE: 2 x M10
- HANDLES: 1 Top, 2 Side
- POLE MOUNT/CAP: Yes
- GRILLE: Steel
- COLOR: Black
Size
- HEIGHT: 708 mm / 27.87 inches
- WIDTH: 437 mm / 17.2 inches
- DEPTH: 389 mm / 15.31 inches
- WEIGHT: 20.5 kg / 45.19 lbs
Shipping informations
- PACKAGE HEIGHT: 725 mm / 28.54 inches
- PACKAGE WIDTH: 550 mm / 21.65 inches
- PACKAGE DEPTH: 505 mm / 19.88 inches
- PACKAGE WEIGHT: 23.7 kg / 52.25 lbs
