5×40W Portman haloLED™ powerful light sources with full halogen emulation
Experience seamless transitions from warm, low-intensity glows to cooler, blinding effects—each light source equaling a 300W halogen lamp. Customize your light show by selecting different dimming curves or strobe mode.
10×8W RGBW LED strips
Operating at 16-bit, they deliver ultra-smooth colour mixing with rich, saturated tones. These strips allow you to elevate the mood or transform the character of the fixture and the entire event, creating an immersive lighting experience.
Screw-free, click-click latch system
Enables effortless connection of fixtures and accessories like bases and coupler adapters. Simply plug the QJS™ spigot into the fixture, then join the accessory or the next fixture in any orientation—perfect for building long lines or angled structures.
Adaptive DMX channels
Automatically adjust the fixture’s channel layout based on its physical position. Just like a smartphone screen rotates when you turn it, the fixtures’s channels flip when you invert the fixture, ensuring consistent and intuitive control. For complete flexibility, you can disable this feature or manually define the top or left side in the settings.
| Dimensions | 118 x 15 x 18 cm (46.5 x 5.9 x 7 in) |
|---|---|
| Weight | 8 kg (17.5 lbs) |
| Rigging | – 2 x 12 mm (1/2 in) holes for clamp on back – base (included) – adaptor (included) with 12 mm (1/2 in) hole for clamp and/or base [Quick Joint System™] |
| Mounting position | Any |
| Input voltage | 100-240V 50Hz/60Hz |
| Power consumption | max 280W |
| Power connector | PowerCon TRUE1 power through |
| Control connector | – 5 PIN XLR (both: in & out) – Art-Net (in) |
| Light sources | – 5 x LED dim-to-warm white – 10 x RGBW strips |
| Color temperature | – 1600-3200K – RGBW |
| CRI | >90 |
| Optics | – High reflective hammered reflector – Opal diffuser |
| Control features | – 6 DMX modes (12-97 DMX channels) – Art-Net – RDM – macros – W-DMX (optional module) |
| User interface | – High-contrast LCD display – Highlighted buttons |
| Warranty | 24 months |
| IP rating | IP20 |
| What’s in the box | – Fixture – 2m power cord (PowerCon TRUE 1<-> no plug) – Base – Adaptor for a hook or a base [QJS™] – User manual |
