AlphaTheta XDJ-AZ Digital DJ System Features:
The XDJ-AZ inherits the layout and feel of the flagship CDJ-3000 and DJM-A9DJM-A9 to give you an intuitive experience. When you perform on the system, it feels as if you’re at one with the decks, allowing for more creative performances. With full-size jog wheels that feel just like those on the CDJ-3000, pitch bending and scratching on the XDJ-AZ are incredibly smooth. The mixer section inherits the intuitive layout of the DJM-A9, with all controls positioned to maximize playability. And it features user-friendly buttons for assigning Beat FX to help you express yourself through the music. So, when you’ve mastered the XDJ-AZ, you’ll be familiar with the way club-standard equipment works and feels, making it much easier to perform at your best in clubs.
Access your cloud-based rekordbox library directly from the XDJ-AZ with CloudDirectPlay. You can use the latest version of your playlists and performance data, such as Hot Cue information, and even update it from the unit. This not only ensures a seamless DJ experience but also allows you to do all your preparation solely from your all-in-one system.
With support for Beatport Streaming, the StreamingDirectPlay feature enables you to directly play tracks from Beatport’s vast dance music library and the latest genre-specific playlists. You’ll even get analysis data such as waveform, BPM, and grid information so you can easily mix new and diverse music into your sets.
As well as playing tracks from USB drives, you can DJ by connecting to your PC/Mac or mobile device. And, if you want to showcase your individuality even further, you can play audio from external devices like turntables and samplers. The unit has a USB Type-C port for PC/Mac connection, so you can use rekordbox for Mac/Windows in Performance mode or Serato DJ Pro*1 and there’s no need for a paid subscription plan for either. And, if you use the Wi-Fi® connection for rekordbox Link Export, you can conveniently access tracks from your PC/Mac or mobile device without needing to plug in cables
Specifications
| Maximum Dimensions (W × D × H) | 895 × 504.1 × 133.4 mm / 35.24” × 19.85” × 5.25” |
|---|---|
| Main unit weight | 13.5 kg / 29.8 lbs. |
| Frequency response | 20 Hz – 20 kHz (USB) |
| S/N ratio | 115 dB (USB) |
| Total harmonic distortion | 0.0018 % (USB) |
| Accessories | Power cord Quick Start Guide Precautions for use Warranty (for some regions) |
| Compatible software | rekordbox for Mac/Windows rekordbox for iOS/Android Serato DJ Pro |
| Inputs | LINE / PHONO × 2 (RCA) MIC × 2 (XLR & 1/4” TRS jack) |
|---|---|
| Outputs | MASTER × 2 (XLR × 1, RCA × 1) BOOTH × 1 (1/4” TRS jack) PHONES × 2 (1/4” stereo jack × 1, 3.5 mm stereo mini jack × 1) |
| USB | USB Type-A × 2 USB Type-C × 1 |
| Others | LAN port (100BASE-TX) × 1 |
| Supported standards | IEEE 802.11 a / b / g / n / ac |
|---|---|
| Frequency band used | 2.4 GHz / 5 GHz |
| Wireless system | Bluetooth ver. 5.3 |
|---|---|
| Compatible codecs | SBC, AAC |
| Frequency band used | 2.4 GHz |
|---|
| Channels | 4 |
|---|---|
| Deck Control | 4 (USB Storage Device) 4 (DJ Software Control) |
| Jog Wheel | 206 mm |
| Jog Feeling | ✓ |
| Sound Color FX | ・DUB ECHO ・NOISE ・SWEEP ・FILTER ・SPACE ・CRUSH |
| Beat FX | ・DELAY ・ECHO ・PING PONG ・SPIRAL ・REVERB ・TRANS ・FILTER ・TRIPLET FILTER ・FLANGER ・PHASER ・ROLL ・TRIPLET ROLL ・HELIX ・MOBIUS |
