Truss light and uplight with bright 3 x 7 W RGB+UV LEDThe flicker-free EUROLITE TL-3 Trusslight is equipped with three 7 Watt 4in1 LEDs each in the colors red, green, blue and UV. It is compact and powerful and therefore very suitable for trussing, stand construction and stage mounting. The TL-3 fits perfectly to the 3-point system ALUTRUSS DECOLOCK DQ3. Also on board are integrated show programs in auto and music mode, direct color selection for 17 colors, dimmer and strobe effect with variably adjustable speed. The trusslight can be used in master/slave mode. Addressing and settings can be done via the integrated control unit with four-digit LED display. You can control the TL-3 either with the included infrared remote control, in standalone mode, via DMX or optionally QuickDMX. Thanks to the IEC mains connections, you can easily connect up to eight devices together.
Variable truss light and uplight with bright 3 x 7 W RGB+UV LED
- Compact and bright, making it perfect for truss installation
- Equipped with 3 x 7 W 4in1 LED in the colors red, green, blue and UV
- DMX-controlled operation or stand-alone operation with Master/Slave function
- Built-in auto and music show programs
- Direct color selection for 17 preset colors
- Functions: static colors, stepless RGB+UV color mixture, internal programs, dimmer, strobe effect with variable speed, Master/Slave operation
- Supports QuickDMX – the wireless DMX system from Eurolite
- Built-in phantom-powered USB port for QuickDMX receivers (accessories)
- DMX control via any standard DMX controller
- Addressing via control panel with 4-digit LED display
- Convenient wireless control via included IR remote control EUROLITE IR-7
- Ideal for booth construction, stages and anywhere trussing is used
- Perfect for ALUTRUSS 3-POINT SYSTEM DECOLOCK DQ3
- Hanging as well as standing installation possible
- M10 threaded insert for suspended installation
- Additional rubber feet when the spot shall be positioned on the floor
- IEC terminals for power linking up to 8 units
- Switch-mode power supply for operation between 100 and 240 volts
- Can be operated in 3 4 4 8 CH mode
- Controlling by IR remote control (provided) Stand-alone DMX Master/slave function QuickDMX via USB (optional) Sound to light via Microphone
- Is in Light J Software EUROLITE LED PC-Control 512 software EASY SHOW LED EASY OPERATOR DELUXE already preprogrammed
- Flicker-free projection
- Effect: UV effect Strobe effect dimmable
| Power supply: | 100-240 V AC, 50/60 Hz |
| Power consumption: | 15 W |
| Power connection: | Mains input IEC connector (M) mounting version Power supply cord with safety plug (provided) |
| Power output: | 1 x Safety contact (F), mounting version |
| Fuse: | F 1 A Fuse replaceable |
| Lamp type: | LED lamp |
| Flash rate: | 1 – 20 Hz |
| DMX channels: | 3 4 4 8 |
| DMX input: | 1 x 3-pin XLR (M) mounting version |
| DMX output: | 1 x 3-pin XLR (F) mounting version |
| Control: | IR remote control (provided) Stand-alone DMX Master/slave function QuickDMX via USB (optional) Sound to light via Microphone Light J Software EUROLITE LED PC-Control 512 software EASY SHOW LED EASY OPERATOR DELUXE |
| Beam angle: | 16° |
| Beam angle (1/2 peak): | 16° |
| Beam angle (1/10 peak): | 33° |
| Housing color: | Black |
| Dimensions: | Width: 12,2 cm Depth: 10,8 cm Height: 11,7 cm |
| Weight: | 890 g |
| Remote control | |
| Battery: | 1 x Button cell 3.0 V CR2025 lithium manganese built-in |
| Legal specifications | |
| Special product: | Not designed for household room illumination |
| intended use: | show effect lighting |
