Specifications:
- Model AT-XP3
- Mounting Half-inch
- Frequency Response 20 to 18,000 Hz
- Channel Separation 20 dB (1 kHz)
- Output Channel Balance 2.0 dB (1 kHz)
- Output Voltage 5.5 mV (at 1 kHz, 5 cm/sec)
- Vertical Tracking Angle 20 degrees
- Vertical Tracking Force Range 2.0 to 4.0g (standard 3.0 g)
- Stylus Shape Conical
- Stylus Size 0.6 mil
- Stylus Construction Bonded Round Shank
- Cantilever Carbon reinforced ABS
- Coil Impedance 6,700 ohms (1 kHz)
- Coil Inductance 550 mH (1 kHz)
- Static Compliance 20 x 10 – 6 cm / dyne
- Dynamic Compliance 6.0 x 10 – 6 cm / dyne (100 Hz)
- Recommended Load Impedance 47,000 Ω
- Recommended Load Capacitance 100-200 pF
- Cartridge Weight 6.2g
- Dimensions 17.2 x 17.8 x 28.3 ( H x W x D mm)
- Replacement Stylus ATN-XP3
- Accessories Included Two 11 mm installation screws;
- Two 8 mm installation screws;
- Two washers
- Two Nut
- Non-magnetic screwdriver
