Specifications:
Light Source:
• 300W Cool White LED Engine
• 50,000 Hour Average LED Life
• 229000 lux @ 2m (8°)
Color:
• Color Wheel: 9 + Open (Including: CTO 3200K & UV)
• Full CMY Color Mixing
GOBOs:
• GOBO Wheel 1: 9 Fixed + Open (1 Beam Reducer for Beam Mode)
• GOBO Wheel 2: 7 Rotating/Replaceable + Open (Size: 26.8mm; Viewable: 20mm)
• Modular design for easy servicing and GOBO replacement
Effects:
• Zoom Range: 8 ~ 46-degrees
• Iris: Motorized 5-100%
• Focus: Motorized
• Frost effect
• Prism 1: Rotating 3-facet Circular
• Prism 2: Rotating 6-facet Linear Rotating
• Prism Layering
Connections:
• Power Input: Locking Power
• Power Pass through: Power Twist @120V or 220V
• USB firmware update port
Control:
• Built-in WiFLY EXR wireless DMX (up to 2500 ft. / 700M line of sight)
• Control Channels: 24, 26 or 38
• DMX Modes: 3
• RDM compatible (Remote Device management)
• Control: 3-pin and 5-pin DMX
• Full color display menu
• Pan / Tilt Correction: Automatic
• Pan / Tilt Lock
• Pan / Tilt Range: 540˚ / 270˚
• Fine Tilt
• Pan/Tilt Speed: Fast to Slow
• Dimming & Fine Dimming: Electronic
Electrical:
• Input Voltage: 100-240V 50Hz/60Hz (Auto Sensing)
• Daisy chain max: 3 fixtures (@120V); 7 fixtures (@230V)
• Power Draw: 398W (3.31A @ 120V; 1.8A @ 220V)
Dimensions/Weight:
• Dimensions (LxWxH): 14.9” x 16.17” x 24.36” / 379 x 411 x 619mm
• Weight: 50 lbs. / 23 kg.
