Specifications:
- An affordable solution for controlling DMX products
- Control up to192 DMX channels
- Programmable up to 240 scenes
- 12 individual fixture channels – Control up to 12 separate intelligent
- lights with up to 16 DMX channels per fixture
- Fixtures with less than 16 DMX channels may be combined on 1 DMX scanner button
- Record up to 6 programmable chases with fade time and speeds
- 8 individual faders provide easy programmability for Intelligent Lighting or Dimmer Packs
- MIDI controllable
- DMX-512, 3-pin XLR signal
- Built-in Microphone
- Remote control: Blackout controlled by MIDI input signal
- Blind function – override chases on the fly
- Use in conjunction with the ELP-DMX20 or the ELD-DMX20
- Polarity switch to accommodate different types of cable requirements
- Power input: DC 9V-12V, 220 mA min. power supply included
- Dimensions: 5.25″ x 19″ x 2.5″ (133 x 483 x 64 mm)
- 19 in. rack mount – 3 rack spaces
- Weight: 5 lbs (2.3 kgs)
- Voltage: 120V/220V
